Flexoptix P.8525G.01 | 25G SR Programmable SFP28 Transceiver

FLEXOPTIX 25G SFP28 SR Programmable Transceiver, 25GBASE-SR, 850nm, 100m, Duplex LC, Multimode MMF

In stock

2.2K+ sold

SKU P.8525G.01 Categories Transceivers 25G, Transceivers & Cables, Transceivers Tag 25G

FLEXOPTIX 25G SFP28 SR Programmable Transceiver, 25GBASE-SR, 850nm, 100m, Duplex LC, Multimode MMF

FLEXOPTIX 25G SFP28 Transceiver Module not only delivers high-performance data transmission over a distance of up to 100m, but it also offers unique programmable functionality, making it a truly Universal Transceiver. With the use of our FLEXBOX, this transceiver can be easily configured to be compatible with almost any vendor, a process that you as a customer can manage effortlessly. However, if you prefer, we at STORDIS are more than happy to provide this configuration service for you free of charge.

Simply download FLEXOPTIX app, connect your FLEXBOX via USB, and insert the Programmable Transceiver. Select your preferred vendor and compatibility, and the configuration is complete in just a few seconds.

Compliant with protocol 10G Ethernet, it accommodates a wide variety of network demands. With 1.2W power consumption and an operating temperature range from 0 to 70°C, this module is an efficient and adaptable choice for data centers, enterprise networks, and service providers. Should your network needs change? The transceiver can be reconfigured again and again, offering unrivaled flexibility.

Whether you wish to utilize the programmability feature yourself or take advantage of our free configuration service, this Universal Transceiver is designed to meet your evolving network needs.

Specifications

General Specifications

Brand	Flexoptix
Data Rate	25G SFP28
Form Factor	SFP28
Model Number	P.8525G.01
Type	SR
Connector Type	LC-Duplex PC

Optical Characteristics

Media Type	Multi-Mode
Receiver Type	PIN
Transmitter Type	VCSEL
Wavelength (TX/RX Range)	840 – 860 nm
Wavelength (TX/RX Typical)	850 nm

Performance

Max Data Rate	25.75 Gbps
Max Distance	100 m (328 ft)

Power Characteristics

Max Power Consumption	1.2 W
Extinction Ratio	2 dB

Environmental

Operating Temperature	0 to 70°C (32 to 158°F)

Additional Features

Power Budget	1.6 dB
DDM	Yes, internally calibrated

Features

No products selected for comparison.

Videos

No videos available.

Reviews

[cusrev_all_reviews sort="DESC" sort_by="date" per_page="10" number="-1" show_summary_bar="true" show_media="true" show_products="true" categories="" product_tags="" tags="" products="current" shop_reviews="true" number_shop_reviews="-1" inactive_products="false" show_replies="false" show_more="5" min_chars="0" avatars="initials" users="all" add_review="true"]

Compatibility List

ALL TRADEMARKS, REGISTERED COMPANIES & REFERENCES CITED ARE THE SOLE PROPERTY OF THEIR RESPECTIVE COMPANY AND ARE USED SOLELY TO ASSIST IN THE IDENTIFICATION OF PRODUCTS.

MSA Standard Compatible	ADVA 1061701115-01 Compatible	Alcatel-Lucent Ent. SFP-25G-SR Compatible
Arista 3rd_Party SFP-25G-SR Compatible	Arista SFP-25G-MR-SR Compatible	Arista SFP-25G-SR Compatible
Aruba Networks(ex. HP Network) 845398-B21 Compatible	Aruba Networks(ex. HP Network) JL484A Compatible	Broadcom SFP28 SR Compatible
Brocade 25G-SFP28-SR Compatible	Chelsio SM25G-SR Compatible	Cisco Systems SFP-10/25G-CSR-S Compatible
Cisco Systems SFP-25G-SR-S Compatible	Cumulus Networks SFP28 SR Compatible	Dell (ex. Force10) W4GPP Compatible
Dell 407-BBWK Compatible	Dell 407-BCBK Compatible	Dell 407-BCGJ Compatible
Dell 407-BCHI Compatible	Extreme 10501 Compatible	Fortinet FG-TRAN-SFP28-SR Compatible
Fortinet FN-TRAN-SFP28-SR Compatible	HP Storage (B-Series) S0K91A Compatible	Huawei SFP-25G-SR (02311KNR) Compatible
Intel E25GSFP28SR Compatible	Juniper JNP-SFP-25G-SR Compatible	Kemp Technologies LM-SFP28-25G-SR Compatible
LANCOM SFP-SR-LC25 Compatible	Lenovo 7G17A03537 Compatible	Matrox SFP28 SR Compatible
NetApp X-48895-00-R6 Compatible	NetApp X65404 Compatible	Netgear SFP28-SR Compatible
Nokia (ex. Alcatel-Lucent) 3HE14834AA Compatible	Nvidia (ex. Mellanox) MMA2P00-AS Compatible	OPNsense DECSFP2825GSR850 Compatible
Oracle 7118017 Compatible	Palo Alto Networks PAN-SFP28-25GBASE-SR Compatible	Pure Storage FA-XR2-25G-Eth-SFP-SR Compatible
QLogic SFP28-25G-SR Compatible	QNAP TRX-25GSFP28-SR Compatible	Rubirk RBK-SFP28-TSR-01 Compatible
SonicWALL 02-SSC-8390 Compatible	Supermicro AOM-SFP28-25GBE-SR Compatible	Synology FTLF8540P4BCL Compatible

Hardware Compatibility List

Speed	Brand	Model	Switch Silicon	Ports
1G	Alpha Networks	BES2348T	Broadcom Trident3-X2	48 × 1G RJ45 + 4 × 25G SFP28
1G	Alpha Networks	SCG60D0-484T	Broadcom Trident3-X2	48 × 1G RJ45 + 4 × 25G SFP28
400G	Alpha Networks	SNJ61D0-320F	Broadcom Trident4-X11	32 × 400G QSFP-DD
1G	Celestica	DS1000	Broadcom Trident3-X2	48 × 1G RJ45 + 8 × 10G SFP+
25G	Celestica	DS2000	Broadcom Trident3-X5	48 × 25G SFP28 + 8 × 100G QSFP28
100G	Celestica	DS3000	Broadcom Trident3-X7	32 × 100G QSFP28
400G	Celestica	DS4000	Broadcom Tomahawk3	32 × 400G QSFP-DD
800G	Celestica	DS4101	Broadcom Tomahawk4	32 × QSFP-DD800
800G	Celestica	DS5000	Broadcom Tomahawk5	64 × OSFP800
1G	Dell Technologies	N3248TE-ON	Broadcom Trident3-X3	48 × 1G RJ45 + 4 × 10G SFP+, 2 × 100G QSFP28
1G	Dell Technologies	N3248P-ON	Broadcom Trident3-X3	48 × 1G RJ45 PoE + 4 x 25G SFP28, 2 x 100G QSFP28
1G	Dell Technologies	E3248P-ON	Broadcom Trident3-X3	48 × 1G RJ45 PoE + 4 x 25G SFP28, 2 x 100G QSFP28
Multi-Gigabit	Dell Technologies	N3248X-ON	Broadcom Trident3-X5	48 × 1G/2.5G/5G/10G RJ45 + 4 x 25G SFP28, 2 x 100G QSFP28
Multi-Gigabit	Dell Technologies	E3248PXE-ON	Broadcom Trident3-X5	48 × 1G/2.5G/5G/10G RJ45 + 4 x 25G SFP28, 2 x 100G QSFP28
Multi-Gigabit	Dell Technologies	N3248PXE-ON	Broadcom Trident3-X5	48 × 1G/2.5G/5G/10G RJ45 PoE + 4 x 25G SFP28, 2 x 100G QSFP28
25G	Dell Technologies	S5212F-ON	Broadcom Trident3-X5	12 × 25G SFP28 + 3 × 100G QSFP28
25G	Dell Technologies	S5224F-ON	Broadcom Trident3-X5	24 × 25G SFP28 + 4 × 100G QSFP28
25G	Dell Technologies	S5248F-ON	Broadcom Trident3-X7	48 × 25G SFP28 + 4 x 25G SFP28, 2 x 100G QSFP-DD
25G	Dell Technologies	S5296F-ON	Broadcom Trident3-X7	96 × 25G SFP28 + 8 × 100G QSFP28
100G	Dell Technologies	Z9264F-ON	Broadcom Tomahawk2	64 × 100G QSFP28
100G	Dell Technologies	S5232F-ON	Broadcom Trident3-X7	32 × 100G QSFP28
100G	Dell Technologies	S5448F-ON	Broadcom Trident4-X9	48 × 100G SFP56-DD + 8x400G QSFP-DD
400G	Dell Technologies	Z9332F-ON	Broadcom Tomahawk3	32 × 400G QSFP-DD
400G	Dell Technologies	Z9664F-ON	Broadcom Tomahawk4	64 × 400G QSFP-DD
400G	Dell Technologies	Z9432F-ON	Broadcom Trident4-X11	32 × 400G QSFP-DD
800G	Dell Technologies	Z9864F-ON	Broadcom Tomahawk5	64 × 800G OSFP112
1G	Edgecore Networks	AS4625-54T	Broadcom Trident3-X2	48 × 1G RJ45 + 6 × 10G SFP+
1G	Edgecore Networks	AS4625-54P	Broadcom Trident3-X2	48 × 1G RJ45 PoE + 6 × 10G SFP+
1G	Edgecore Networks	AS4630-54TE	Broadcom Trident3-X3	48 × 1G RJ45 + 4 × 25G SFP28, 2 × 100G QSFP28
1G	Edgecore Networks	AS4630-54PE	Broadcom Trident3-X3	48 × 1G RJ45 PoE + 4 × 25G SFP28, 2 × 100G QSFP28
Multi-Gigabit	Edgecore Networks	AS4630-54NPE	Broadcom Trident3-X3	36 × 1.G/2.5G RJ45, 12 × 1G/2.5G/5G/10G RJ45 PoE + 4 × 25G SFP28, 2 × 100G QSFP28
10G	Edgecore Networks	AS5835-54T	Broadcom Trident3-X5	48 × 10G RJ45 + 6 × 100G QSFP28
10G	Edgecore Networks	AS5835-54X	Broadcom Trident3-X5	48 × 10G SFP+ + 6 × 100G QSFP28
25G	Edgecore Networks	AS7326-56X	Broadcom Trident3-X7	48 × 25G SFP28 + 8 × 100G QSFP28
100G	Edgecore Networks	AS7712-32X	Broadcom Tomahawk	32 × 100G QSFP28
100G	Edgecore Networks	AS7816-64X	Broadcom Tomahawk2	64 × 100G QSFP28
100G	Edgecore Networks	S7726-32X	Broadcom Trident3-X7	32 × 100G QSFP28
400G	Edgecore Networks	AS9716-32D	Broadcom Tomahawk3	32 × 400G QSFP-DD
400G	Edgecore Networks	AS9736-64D	Broadcom Tomahawk4	64 × 400G QSFP-DD
400G	Edgecore Networks	AS9726-32DB	Broadcom Trident4-X11	32 × 400G QSFP-DD
800G	Edgecore Networks	AIS800-64D	Broadcom Tomahawk5	64 × QSFP-DD800
25G	Extreme Networks	SLX 9150-48Y	Broadcom Trident3-X7	48 × 25G SFP28 + 6 × 100G QSFP28
100G	Extreme Networks	SLX 9250-32C	Broadcom Trident3-X7	32 × 100G QSFP28
400G	Micas Networks	M2-W6920-32QC2X	Broadcom Tomahawk3	32 × 400G QSFP-DD
400G	Micas Networks	M2-W6930-64QC	Broadcom Tomahawk4	64 × 400G QSFP-DD
25G	QCT	T4048-IX8	Broadcom Trident3-X5	48 × 25G SFP28 + 8 × 100G QSFP28
100G	QCT	T7064-IX4	Broadcom Tomahawk2	64 × 100G QSFP28
100G	QCT	T7032-IX7	Broadcom Trident3-X7	32 × 100G QSFP28
400G	QCT	T9032-IX9	Broadcom Tomahawk3	32 × 400G QSFP-DD
25G	UfiSpace	S8901-54XC	Broadcom Trident3-X5	48 × 25G SFP28 + 6 × 100G QSFP28
100G	UfiSpace	S9100-32X	Broadcom Trident3-X7	32 × 100G QSFP28
1G	Wistron	SO-BI48B-4E	Broadcom Trident3-X2	48 × 1G RJ45 + 4 × 25G SFP28
